Hitkn 108 Autoclave Horizontal

Name: Hitkn 108 Autoclave Horizontal
Brand: HITKN OVERSEAS
Price: 720000 INR
Availability: InStock

Price 720000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Hitkn 108 Autoclave Horizontal Specification

Type
Pre-vacuum Horizontal Autoclave

Chamber Size
800 x 800 x 1500 mm

Chamber Thickness
6-8 mm, Stainless Steel 316L

Outer Size
1570 x 1360 x 2200 mm

Compressed Air
0.6-0.8 Mpa

Door Type
Fully Automatic Horizontal Sliding Door

Design Pressure
0.245 Mpa

Working Pressure
0.22 Mpa

Design Temperature
137C

Heat Uniform
1C Variation

Insulation
Mineral Wool, 50mm thickness

Net Weight
Approx 1550 kg

Recording Parameters
Digital Printer & USB Port

Spraying Mode
Uniform Spraying through High-efficiency Nozzles

Outer Trolley
Stainless Steel, Heavy Duty

Inner Trolley
Stainless Steel, Removable

Spraying Piping
316L Stainless Steel

Steam
External Steam Generator or In-built Steam Supply

Sterilizing Temperature
121C to 134C

Working Temperature
134C

Sterilization Time
0-99 min Programmable

Temperature Scope
50C-134C

Piping System
Corrosion Resistant SS Piping

Valves
High Quality Pneumatic Valves

Power Consumption
14 kW

Display
Large Digital Display for Parameters

Water Consumption
120 Litres Per Cycle

Service Support
On-site Technical Assistance and Training Provided

Accessories Included
Trolleys, Baskets, Documentation, Installation Kit

Power Supply
380V, 50Hz, 3 Phase

Safety Features
Automatic Pressure and Temperature Control, Door Interlock System, Over-temperature & Over-pressure Protection

Vacuum Pump
High Performance Oil-sealed Rotary Vane Type

Noise Level
<70 dB

Standards Compliance
Meets ISO 9001, EN285 and CE Certifications

User Capacity
Up to 4 Trolleys Per Cycle

Material of Construction
Stainless Steel 316L (Chamber and Door), Outer body SS304

Door Gasket
Silicon, Autoclavable

Application
Hospital, Pharmaceutical, Microbiology, Laboratory Use

Control System
Microprocessor Based PLC with Touch Screen HMI

Hitkn 108 Autoclave Horizontal Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
7 Days

About Hitkn 108 Autoclave Horizontal

Introducing the New Hitkn 108 Autoclave Horizontal-a laureate among sterilization units for hospital, pharmaceutical, microbiology, and laboratory environments. Select advanced safety with automatic pressure and temperature control, door interlock, and over-pressure protection for optimum operation. Its dazzling high-capacity chamber (316L stainless steel) handles up to four trolleys per cycle with uniform spraying and programmable sterilization. Grab yours today for superb efficiency: microprocessor PLC with touch HMI, digital display, and reliable documentation support. Complies with ISO 9001, EN285, and CE standards for top-tier performance and safety.

Plant Application and General Use of Hitkn 108 Autoclave Horizontal

The Hitkn 108 Autoclave Horizontal is expertly designed for sterilization processes in hospitals, pharmaceutical facilities, and research laboratories. This powerful unit excels for both general and specialized plant applications, ensuring a safe and controlled environment whenever you need microbiological, surgical, or laboratory instruments sterilized. Its programmable system and heavy-duty construction enable broad utility while maintaining precise temperature and pressure settings for a variety of sterilization cycles and specific end uses.

Domestic & Export Market and Packaging Insight for Hitkn 108 Autoclave

The Hitkn 108 Autoclave Horizontal commands high market value in India's main domestic market, as well as prominent export markets across Asia, Africa, and the Middle East. Proposal amounts are structured for competitive sectors worldwide. Every unit is meticulously packaged in secure, industrial-grade materials to ensure safe dispatching and delivery. Robust documentation accompanies each delivery, confirming specifications and facilitating easy installation for rapid entry into active use.

FAQ's of Hitkn 108 Autoclave Horizontal:

Q: How does the Hitkn 108 Autoclave Horizontal ensure safe sterilization processes?

A: It employs a microprocessor-based PLC with automatic pressure and temperature control, door interlock systems, and over-temperature and over-pressure protection. These advanced features are designed to maximize safety and operational reliability during every sterilization cycle.

Q: What are the primary usage applications for the Hitkn 108 Autoclave Horizontal?

A: This autoclave is suitable for sterilizing medical instruments, pharmaceutical items, microbiology tools, and laboratory glassware. Its programmable cycles and high capacity make it adaptable for use in hospitals, pharmaceutical production, and scientific research settings.

Q: Where can the Hitkn 108 Autoclave Horizontal be installed and operated?

A: The autoclave is engineered for hospital sterilization plants, pharmaceutical manufacturing facilities, and laboratory centers in both domestic and international markets. Its versatile installation kit supports flexible placement.

Q: When should I use the programmable sterilization function?

A: Use the programmable sterilization function when you require precise control over sterilization time (ranging from 0-99 minutes) and temperature (50C-134C), especially for sensitive or critical instruments needing customized cycles.

Q: What benefits does the large digital display offer for users?

A: The large digital display makes it easy to monitor process parameters in real time, enhancing operational clarity, simplifying documentation, and providing instant feedback for efficient cycle management.

Q: How is after-sales support managed for the Hitkn 108 Autoclave Horizontal?

A: Comprehensive, on-site technical assistance and user training are provided to ensure smooth operation, ongoing maintenance, and rapid resolution of any technical queries post-installation.
